Firma de clics para redes de publicidad

Ejemplo de URL de clic en OneLink (multiplataforma):

https://yourbrand.onelink.me/qsWL?pid=mediasource_int&advertising_id=12345678-1234-1234-1234-123456789012
&af_ad_type=video&af_adset=MMP&clickid=sdkfjasksjskdfj9845weh&af_siteid=my_site&af_viewthrough_lookback=2h&c=my_campaign
&expires=1689695615

Ejemplo de objeto json para la firma (antes de eliminar los espacios en blanco):

[
	["link_domain","yourbrand.onelink.me"],
	["link_path","qswl"],
	["pid","mediasource_int"],
	["af_siteid","my_site"],
	["clickid","12345"],
	["expires","1689695615"]
]

Ejemplo de objeto json para la firma (tras eliminar los espacios en blanco)

[["link_domain","yourbrand.onelink.me"],["link_path","qswl"],["pid","mediasource_int"],["template-id","qswl"],["af_siteid","my_site"],["clickid","12345"],["expires","1689695615"]]

URL del clic final con la firma:

https://yourbrand.onelink.me/qsWL?pid=mediasource_int&advertising_id=12345678-1234-1234-1234-123456789012
&af_ad_type=video&af_adset=MMP&af_siteid=my_site&af_viewthrough_lookback=2h&c=my_campaign
&expires=1689695615
&signature_v2=WIfCmfLAPSsVrBTqCqfihMeLCnbE4dIAlhHF84WsiWA

[
  {"index":1, "name":"pid", "mandatory":true},
  {"index":2, "name":"af_prt", "mandatory":false},
  {"index":3, "name":"af_siteid", "mandatory":true},
  {"index":4, "name":"clickid", "mandatory":true},
  {"index":5, "name":"expires", "mandatory":true},
  {"index":6, "name":"af_engagement_type", "mandatory":false},
  {"index":7, "name":"af_click_lookback", "mandatory":false},
  {"index":8, "name":"af_viewthrough_lookback", "mandatory":false},
  {"index":9, "name":"af_reengagement_window", "mandatory":false},
  {"index":10, "name":"is_retargeting", "mandatory":false},
  {"index":11, "name":"af_ip", "mandatory":false},
  {"index":12, "name":"advertising_id", "mandatory":false},
  {"index":13, "name":"oaid", "mandatory":false},
  {"index":14, "name":"fire_advertising_id", "mandatory":false},
  {"index":15, "name":"idfa", "mandatory":false},
  {"index":16, "name":"idfv", "mandatory":false}
]

package main

import (
	"crypto/hmac"
	"crypto/sha256"
	"encoding/base64"
	"encoding/json"
	"errors"
	"fmt"
	"io"
	"net/url"
	"os"
	"strings"
	"time"
)

type Param struct {
	Name      string
	Mandatory bool
}

func LoadSupportedParams() ([]Param, error) {
	path := "./signing-supported-params.json"
	jsonFile, _ := os.Open(path)
	defer jsonFile.Close()
	byteValue, err := io.ReadAll(jsonFile)
	if err != nil {
		return nil, errors.New("failed loading " + path)
	}
	var params []Param
	_ = json.Unmarshal(byteValue, &params)
	return params, nil
}

func computeHmac256(message, secret string) (res string, errResult error) {
	defer func() {
		if r := recover(); r != nil {
			errResult = r.(error)
			fmt.Println("failed to invoke ComputeHmac256. err: %+v", errResult)
			res = ""
			return
		}
	}()

	key := []byte(secret)
	h := hmac.New(sha256.New, key)
	h.Write([]byte(message))
	return base64.URLEncoding.WithPadding(base64.NoPadding).EncodeToString(h.Sum(nil)), nil
}

// this function accepts a click url, a ttl for the click in seconds, and the list of supported params
// the function:
// 1. adds the expiration to the click based on the provided ttl
// 2. builds a json for the signature
// 3. create an HMAC256 signature
// 4. adds the signature to the click url
func signURLV2(originalURL string, secret string, clickTtlSeconds int64, supportedParams []Param) (signedURL string, err error) {

	//add an expiration to the click
	expires := time.Now().UTC().Unix() + clickTtlSeconds
	urlWithExpired := fmt.Sprintf("%s%s%d", originalURL, "&expires=", expires)

	//parse the url
	parsedURL, err := url.Parse(urlWithExpired)
	if err != nil {
		return "", errors.New("failed parsing URL")
	}

	//build a json from the url
	jsonStr, err := buildJSONFromURLV2(parsedURL, supportedParams)
	if err != nil {
		return "", err
	}

	//create a signature
	signatureV2, err := computeHmac256(jsonStr, secret)
	if err != nil {
		fmt.Println("Failed to computeHMAC256 for url %s. err: %+v", jsonStr, err)
		return "", errors.New("fail to computeHMAC256 for url")
	}

	//add the signature to the url
	signedURL = fmt.Sprintf("%s%s%s", urlWithExpired, "&signature_v2=", signatureV2)

	return signedURL, nil

}

// this function builds a json from a given click url.
// It returns a string representation of the json ready to be signed.
func buildJSONFromURLV2(parsedURL *url.URL, supportedParams []Param) (string, error) {
	//initiate an empty json in the structure [[key-1,val-1],[key-2,val-2]...[key-n,val-n]]
	var jsonData [][2]string

	//add the url host domain to the json
	domain := parsedURL.Host
	param := [2]string{"link_domain", domain}
	jsonData = append(jsonData, param)

	//add the path (app-id or template-id) to the json
	path := parsedURL.Path
	if len(path) > 1 {
		param := [2]string{"link_path", path[1:]}
		jsonData = append(jsonData, param)
	}

	//loop over the ordered list of supported parameters and add them to the json
	for i := 0; i <len(supportedParams); i++ {name := supportedParams[i].Name val := parsedURL.Query().Get(name) if len(val) > 0 {
			param := [2]string{name, val}
			jsonData = append(jsonData, param)
		} else if supportedParams[i].Mandatory {
			return "", errors.New("missing mandatory param: " + name)
		}
	}

	//generate string representation of the json object
	jsonObj, _ := json.Marshal(jsonData)
	return strings.ToLower(string(jsonObj)), nil
}

func main() {

	supportedParams, err := LoadSupportedParams()
	if err != nil {
		fmt.Println("Error: ", err)
		os.Exit(1)
	}

	var secretKey = "tqJU4Qd/eFTEWfqW7KCG9asDO0bmZoFzv8GY3VPSPAM="
	var clickTtlSeconds int64 = 60
	var originalUrl = "https://yourbrand.onelink.me/qsWL?pid=mediasource_int&advertising_id=12345678-1234-1234-1234-123456789012&clickid=1234&af_ad_type=video&af_adset=MMP&af_siteid=my_site&af_viewthrough_lookback=2h&c=my_campaign"

	fmt.Println("Original URL: ", originalUrl)

	signedUrl, err := signURLV2(originalUrl, secretKey, clickTtlSeconds, supportedParams)
	if err != nil {
		fmt.Println("Error: ", err)
		os.Exit(1)
	} else {
		fmt.Println("Signed URL: ", signedUrl)
	}
}

Método de generación de clave secreta

POST https://hq1.appsflyer.com/api/p360-click-signing/secret?ttlHours=<ttlHours>

curl --location --request POST 'https://hq1.appsflyer.com/api/p360-click-signing/secret?ttlHours=36' \
-H 'Authorization: Bearer {API V2.0 token available to the admin in the dashboard.}'

{
	"secret-key-id": "59ad6547-affc-45eb-a6c9-9805f88ee755",
	"secret-key": "zGW6Rhrmb8+vuhHtL/Kp6rW5Ci9PNsjH1J5MGO9SIeg=",
	"expiration": 1610533263
}

Método de revocación de la clave secreta

DELETE https://hq1.appsflyer.com/api/p360-click-signing/secret/<secret-id>

curl --location --request DELETE 'https://hq1.appsflyer.com/api/p360-click-signing/secret/59ad6547-affc-45eb-a6c9-9805f88ee755' \
-H 'Authorization: Bearer {API V2.0 token available to the admin in the dashboard.}'

Método de prueba

POST https://hq1.appsflyer.com/api/p360-click-signing/test

curl --location --request POST 'https://hq1.appsflyer.com/api/p360-click-signing/test' \
-H 'Authorization: Bearer {API V2.0 token available to the admin in the dashboard.}' \
--header 'Content-Type: application/json' \
--data-raw '{
   "url": "https://app.appsflyer.com/com.app.id?pid=adnetwork_int&c=my_campaign&clickid=sdkfjasksjskdfj9845weh&af_site_id=12345&expires=1597657118&signature=8fnDVzZP_WRZnv3KNJaREOEfvB5p9oRc_XlKEvUo8gk"
}'

{
	"test-status":"Passed / Failed",
	"message": "Invalid signature"
}

Configurar método de modo

POST https://hq1.appsflyer.com/api/p360-click-signing/config/mode/<mode>

curl --location --request POST 'https://hq1.appsflyer.com/api/p360-click-signing/config/mode/report-only' \
-H 'Authorization: Bearer {API V2.0 token available to the admin in the dashboard.}'

Configurar el método del disyuntor

POST https://hq1.appsflyer.com/p360-click-signing/config/circuit-breaker

curl --location --request POST 'https://hq1.appsflyer.com/api/p360-click-signing/config/circuit-breaker' \
-H 'Authorization: Bearer {API V2.0 token available to the admin in the dashboard.}'
--data-raw '{
"status":"enabled"
}'

Obtener método de configuración

GET https://hq1.appsflyer.com/api/p360-click-signing/config

curl --location --request GET 'https://hq1.appsflyer.com/api/p360-click-signing/config' \
-H 'Authorization: Bearer {API V2.0 token available to the admin in the dashboard.}'

{
	"mode": "report-only",
	"active-key-ids": [
		{
			"secret-key-id": "59ad6547-affc-45eb-a6c9-9805f88ee755",
			"expiration": 1610533263
		}
	],
	"excluded-app-ids": [
		"app-id-1", 	"app-id-2"
	]

}

Método de reporte

GET https://hq1.appsflyer.com/api/p360-click-signing/report

curl --location --request GET 'https://hq1.appsflyer.com/api/p360-click-signing/report?start-date=2021-01-07T07&end-date=2021-01-17T12' \
-H 'Authorization: Bearer {API V2.0 token available to the admin in the dashboard.}' \

Excluir método de aplicación

POST https://hq1.appsflyer.com/api/p360-click-signing/config/excluded-app/<app-id>

curl --location --request POST 'https://hq1.appsflyer.com/api/p360-click-signing/config/excluded-app/appname.com' \
-H 'Authorization: Bearer {API V2.0 token available to the admin in the dashboard.}'

Eliminar el método de aplicaciones excluidas

DELETE https://hq1.appsflyer.com/api/p360-click-signing/config/excluded-app/<app-id>

curl --location --request DELETE 'https://hq1.appsflyer.com/api/p360-click-signing/config/excluded-app/appname.com' \
-H 'Authorization: Bearer {API V2.0 token available to the admin in the dashboard.}'

package sign;

import javax.crypto.Mac;
import javax.crypto.spec.SecretKeySpec;
import java.security.InvalidKeyException;
import java.security.NoSuchAlgorithmException;
import java.util.Base64;

.
.
.

String clickUrl = "https://app.appsflyer.com/com.app.id?pid=adnetwork_int&c=my_campaign&clickid=sdkfjasksjskdfj9845weh&af_site_id=12345";
String secretKey = "secret_key";
int ttlMinutes = 5;


//add expiration to the click URL
long expiration = System.currentTimeMillis() + (60000L * ttlMinutes);
clickUrl += "&expires="+expiration;

//create a SecretKey object from the given key string
SecretKeySpec signingKey = new SecretKeySpec(secretKey.getBytes(), "HmacSHA256");
Mac mac = Mac.getInstance("HmacSHA256");
mac.init(signingKey);

//generate a signature from the click url and encode it with base64 without padding
String generatedSignature =
Base64.getUrlEncoder().withoutPadding().encodeToString(mac.doFinal(clickUrl.getBytes()));

//add the signature to the click URL
String signedClickUrl = clickUrl + "&signature=" + generatedSignature;

AppsFlyer detiene la validación de firmas de clics y vuelve al modo de sólo reporte cuandomás del 90% de los clics en una hora no superan la validación de firmas.

Esto sirve para proteger a tu empresa de un posible problema técnico y te permite encontrar la causa de la anomalía:

• Si compruebas que la firma funciona como se espera y los clics se bloquean correctamente, desactiva el disyuntor mediante el método de configuración del disyuntor.
• Si observas que los clics se bloquean incorrectamente:
  1. Asegúrate de que tienes una clave secreta válida comprobando la configuración de firma de clics mediante el método obtener configuración.
  2. Utiliza el reporte de firma de clics para obtener más información sobre los clics bloqueados e investigar las fuentes (agencia/app-iDs) y los motivos de los clics no válidos.
• Si encuentras un problema con una aplicación específica debido a una integración no estándar, excluye esta aplicación de la validación de firma de clics utilizando la API de excluir aplicación API.
• Si encuentras un problema con tu configuración:
  1. Continúa funcionando en modo sólo reporte.
  2. Arregla el proceso de firma de clics por tu parte.
  3. Comprueba los resultados en el reporte de firma de clics yvuelve a activar la validación de firma de clics cuando veas que los clics se están validando como se esperaba.
